Rubber Bushings
LIXU
With over 15 years of experience in rubber components production, Lixu Rubber specializes in OEM custom rubber bushings for agricultural machinery. We know farming equipment operates in the harshest environments – dust, mud, extreme temperatures, and heavy vibration. That’s why our agricultural rubber bushings are engineered with premium materials and precision molding technology to deliver exceptional durability, anti-vibration performance, and long service life. We supply custom farm machinery rubber bushings to global clients, including tractor manufacturers, harvester brands, and agricultural equipment suppliers, with full OEM/ODM support tailored to your drawings, samples, and application needs. At Lixu Rubber, We build reliable rubber bushings that keep your agricultural machinery running smoothly season after season. At LIXU RUBBER, quality is non-negotiable for agricultural equipment – a failed bushing can stop an entire harvest. We are ISO 9001 certified, and all our custom rubber bushings for agricultural machinery comply with RoHS, REACH, and WRAS standards. Every batch undergoes 3-layer inspection: raw material testing (tensile strength, hardness, chemical resistance), in-process monitoring (molding temperature, pressure), and final testing (vibration resistance, wear resistance, dimensional accuracy). We provide full test reports for every order.
| Rubber Material | Key Advantages | Limitations | Suitable Agricultural Applications |
|---|---|---|---|
| EPDM Rubber | Excellent UV/ozone resistance, high-temperature resistance (-40℃ to +120℃), anti-aging, good water/chemical resistance | < Ideal oil resistance | Tractor body bushings, harvester frame bushings, outdoor equipment components |
| NBR (Nitrile Rubber) | Superior oil/grease resistance, good wear resistance, high tensile strength | < UV resistance, easy to age in outdoor | Tractor engine bushings, transmission system bushings, oil-contacting components |
| Polyurethane (PU) | Exceptional wear resistance, high load-bearing capacity, good elasticity | < Low-temperature flexibility (-20℃ limit) | Heavy-duty tractor bushings, harvester cutter bushings, high-wear components |
| Natural Rubber (NR) | Excellent elasticity, high resilience, good shock absorption | Poor oil/UV resistance, easy to wear | Light-load bushings, non-oil-contacting components, temporary use equipment |
Seeders, sprayers, and hay balers – we provide custom rubber bushings for all special-purpose agricultural equipment, tailored to your specific component design and working requirements.
| Parameter | Standard Specification | OEM Customization Range |
|---|---|---|
| Material | EPDM, NBR, PU, NR | Custom material blends (EPDM/NBR, etc.) |
| Hardness (Shore A) | 40° - 80° | 30° - 90° (soft to hard) |
| Temperature Range | -40℃ to +120℃ | -50℃ to +150℃ (special compound) |
| Size Range | Inner Diameter: 10mm - 200mm; Outer Diameter: 20mm - 300mm; Length: 10mm - 150mm | Custom sizes per CAD drawings/samples |
| Tolerance | ±0.03mm | ±0.01mm (precision grade) |
| Certifications | ISO 9001, RoHS, REACH, WRAS | Custom certifications per market requirements |
| Wear Resistance | ≤ 0.05g (ASTM D2228) | ≤ 0.03g (premium material) |
As a professional rubber bushings factory, We have 30+ sets of advanced compression molding machines, CNC precision cutting tools, and rubber mixing equipment, with a monthly production capacity of 800,000 pieces of agricultural rubber bushings. Our R&D team has 12+ years of experience in agricultural rubber component design, capable of solving complex customization needs and providing technical support for your new equipment development.
LIXU RUBBER offers a full range of agricultural rubber components, including OEM custom rubber bushings for agricultural machinery, farm machinery rubber bushings, tractor suspension bushings, harvester rubber bushings, anti-vibration rubber bushings for farming equipment, high-wear agricultural rubber bushings, oil-resistant NBR rubber bushings for tractors, and EPDM rubber bushings for outdoor farm equipment. All our products are engineered to meet the tough demands of agricultural operations, trusted by global farming equipment brands for quality and durability.
For tractors, we recommend EPDM/NBR blended rubber bushings – they balance oil resistance (for engine/transmission components) and UV/anti-aging performance (for outdoor use). If the bushing is in an oil-contacting area, pure NBR is better; for frame/suspension bushings, EPDM is ideal for long-term outdoor service.
Yes. We can scan and reverse-engineer your old agricultural rubber bushings to create precise molds, even without CAD drawings. Our precision measuring equipment ensures the new bushings are 1:1 matched to your samples, with the same size, hardness, and performance.
Under normal farming conditions, our EPDM/NBR rubber bushings have a service life of 5-8 years – 2-3 times longer than ordinary rubber bushings. The service life may vary slightly based on working intensity (e.g., heavy-load vs. light-load) and environment (e.g., high humidity vs. dry areas).
Absolutely. We formulate our agricultural rubber bushings with chemical-resistant compounds that can withstand common fertilizers, pesticides, and soil chemicals. They won’t swell, crack, or degrade when exposed to these substances, ensuring stable performance in farm fields.
Our MOQ for OEM custom rubber bushings is 500 pieces – we support small-batch customization for new product development. For mass production, the more you order, the more competitive the price. We also accept trial orders of 100-200 pieces for testing.
Yes. Our R&D team has rich experience in agricultural rubber component design. We can help you select the right material, determine the optimal bushing structure, and optimize shock absorption performance based on your new equipment’s working conditions. We provide 2D/3D drawing feedback and technical advice for free.
We use CNC precision molding machines and automated measuring equipment (with an accuracy of ±0.001mm) to ensure dimensional tolerance within ±0.03mm. Every batch of custom bushings undergoes 100% dimensional inspection – we will send you a detailed measurement report with your order.
Yes. We provide a 2-year after-sales warranty for our OEM custom rubber bushings. If you encounter quality issues (e.g., cracking, deformation) within the warranty period (excluding human damage), we will replace the products for free or refund your money. Our technical team also provides on-site installation guidance if needed.
